Stamping Parts

The Microscopic Cornerstone of Electrical Systems

As China's leading stamping parts manufacturer for low-voltage electrical equipment, HAIPART understands that each stamping component serves as a fundamental building block for current transmission, structural support, and safety protection.

Millimeter Design, Micron Control

We know that a 0.1mm deviation in circuit breaker terminals can cause poor contact, and insufficient flatness in contactor magnetic sheets can compromise electromagnetic performance. That's why we adhere to the standard of "millimeter-level design with micron-level control" to deliver highly adaptive stamping solutions.

Why Choose HAIPART Stamping Parts?

✅ Multi-Material Compatibility

T3/T2 Purple Copper (98% IACS conductivity)
10# Steel (Yield strength ≥245MPa)
H62 Brass (38%-42% zinc content)
QSn6.5-0.1 Phosphor Bronze (Anti-stress relaxation)

✅ Precision Surface Treatment

Acid washing (Ra≤0.8μm)
Localized silver plating (3μm, contact resistance <10μΩ)
Blue-white zinc plating (6μm, salt spray resistance 96h)

✅ Quality Commitment

Stamping precision ±0.02mm
Compliance with GB/T 1804-m tolerance standard
ROHS/REACH environmental certification
10-year quality guarantee

Material & Surface Treatment Options

Material	Surface Treatment	Typical Applications
T2 Purple Copper	Local silver plating (3μm)	High-reliability MCB contacts
H62 Brass	Acid washing	Terminal blocks, connectors
QSn6.5-0.1 Phosphor Bronze	Copper-tin plating	Spring contacts, shrapnel contactors
10# Steel	Blue-white zinc plating (6μm)	Structural components, sensor housings
Q195 Steel	Zinc plating	Cost-sensitive applications
