Professional Low Voltage Parts Manufacturer

Stamping Parts

The Microscopic Cornerstone of Electrical Systems


As China's leading stamping parts manufacturer for low-voltage electrical equipment, HAIPART understands that each stamping component serves as a fundamental building block for current transmission, structural support, and safety protection.


Millimeter Design, Micron Control


We know that a 0.1mm deviation in circuit breaker terminals can cause poor contact, and insufficient flatness in contactor magnetic sheets can compromise electromagnetic performance. That's why we adhere to the standard of "millimeter-level design with micron-level control" to deliver highly adaptive stamping solutions.


Why Choose HAIPART Stamping Parts?


✅ Multi-Material Compatibility

  • T3/T2 Purple Copper (98% IACS conductivity)

  • 10# Steel (Yield strength ≥245MPa)

  • H62 Brass (38%-42% zinc content)

  • QSn6.5-0.1 Phosphor Bronze (Anti-stress relaxation)


✅ Precision Surface Treatment

  • Acid washing (Ra≤0.8μm)

  • Localized silver plating (3μm, contact resistance <10μΩ)

  • Blue-white zinc plating (6μm, salt spray resistance 96h)


✅ Quality Commitment

  • Stamping precision ±0.02mm

  • Compliance with GB/T 1804-m tolerance standard

  • ROHS/REACH environmental certification

  • 10-year quality guarantee


Material & Surface Treatment Options


Material Surface Treatment Typical Applications
T2 Purple Copper Local silver plating (3μm) High-reliability MCB contacts
H62 Brass Acid washing Terminal blocks, connectors
QSn6.5-0.1 Phosphor Bronze Copper-tin plating Spring contacts, shrapnel contactors
10# Steel Blue-white zinc plating (6μm) Structural components, sensor housings
Q195 Steel Zinc plating Cost-sensitive applications


Application-Specific Solutions


Our stamping parts are engineered for various electrical components including:

  • MCB (Miniature Circuit Breaker)

  • Wall switches

  • Sensors

  • Air flow valves (Stretch cap components)

  • Sensor housings

  • MCCB (Molded Case Circuit Breaker)

  • Shrapnel contactors


High-Reliability Applications

Nuclear Power, Marine, Critical Infrastructure

  • Recommended: T2 Purple Copper + Local Silver Plating.

  • Passes IEC 60947-2 short-circuit withstand test.

  • Exceptional conductivity and corrosion resistance.


Cost-Sensitive Projects

Residential Buildings, Commercial Distribution

  • Recommended: Q195 Steel + Zinc Plating.

  • Reduces material costs by 30%.

  • Maintains performance for standard applications.


Get Precision Stamping Solutions


Download our comprehensive product catalog for complete specifications
